spigot truss
aluminum spigot truss
Model No: S290

290*290mm Aluminum Spigot Square Truss

Spigot truss made of aluminum. It's designed for quick and easy assembly to meet various construction needs. Solid conical connectors and tapered pins for easy install, ensure secure connections.
Delivery :
EXW
minimum order :
10 pieces
Supply Ability :
10000pieces / Month
Stock Time :
15Day
Country of Origin :
China
Quantity :
US $46.88 - US $200.00 / pieces
add to cart
Contact Now

Parameter:

Material: Aluminum Alloy 6061-T6;

Main Tube: 50*3mm,

Vice Tube: 20*2mm,

4-sides Brace Tube: 20*2mm,

Safety Span: 14m

Length: 0.5mm, 1mm, 1.5mm, 2mm, 2.5mm, 3mm, 4mm

Weight: 4.7kg, 7.9kg, 10.9kg, 13.4kg, 17kg, 19.5kg

Detail:

290*290mm aluminum spigot truss made of 6061-T6 aluminum alloy material, comprising main tubes with a diameter of 50mm and wall thickness of 3mm, as well as secondary tubes with a diameter of 20mm and wall thickness of 2mm.

GFtruss offer standard spigot trusses in various sizes, strengths, and lengths, with lengths ranging from 0.5m to 4m.

Customizable truss structures suitable for various scenes such as large concerts, small events, sports arenas, bars, schools, and more. Made of 6061-T6/6082-T6 aluminum alloy material, aluminum spigot truss undergo TUV load testing for quality assurance.

Feature:

* Compared to traditional steel trusses, aluminum spigot truss has a lighter weight, making it easy to transport, assemble, and disassemble.

* Despite its lightweight, the aluminum alloy material possesses high strength, providing sturdiness and durability to withstand significant loads.

* Aluminum spigot truss exhibits excellent corrosion resistance and weather resistance, ensuring prolonged usage without rusting and with low maintenance costs.

* Featuring a modular design with standard connectors and structures, enabling flexible installation and use in different venues.

* Aluminum spigot truss suit for exhibitions, gantry system, stage lighting, and truss structures.



Application:
